G6M-1A DC24
Manufacturer:
Omron
Mfr.Part #:
G6M-1A DC24
Datasheet:
Description:
Power Relays Through Hole 5 mA 4.8 kΩ 24 V General Purpose
| Parameter | Value |
|---|---|
| Length | 20.3 mm |
| Width | 5.08 mm |
| Termination | PC Pin |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Voltage Rating (AC) | 380 V |
| Number of Pins | 4 |
| Height | 17.7 mm |
| Packaging | Bulk |
| Depth | 5.08 mm |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Weight | 4 g |
| Contact Material(Contact Finish) | Silver |
| Current Rating | 3 A |
| Max Current Rating | 5 A |
| Max Voltage Rating (DC) | 125 V |
| Approvals | CSA, UL, VDE |
| Throw Configuration | SPST |
| Max Voltage Rating (AC) | 270 V |
| Coil Voltage (DC) | 24 V |
| Coil Current | 5 mA |
| Coil Type | Non-Latching |
| Coil Resistance | 4.8 kΩ |
| Relay Type | General Purpose |
| Operate Time | 10 ms |
| Release Time | 5 ms |
| Contact Current Rating | 3 A |
| power consumption | 120 mW |
| Termination Style | PC Pin |
| Switching Voltage | 270 VAC, 125 VDC |
| Coil Power | 120 mW |
| Must Operate Voltage | 16.8 V |
| Must Release Voltage | 2.4 V |
